MS-H-S BlueSpin Classic Magnetic Hotplate Stirrer

Detailed description

MS-H-S
BlueSpin Classic Magnetic Hotplate Stirrer

Features of MS-H-S

- Stainless steel with ceramic coated hotplate resists to corrosion
- Separated safety circuit, automatically stop heating when temperature over 350℃
- Motor with electronic speed control, constant speed even during changes in load
- Variable speed of motor
- High magnetic adhesion, prevent the stirrer bar escape
- Enclosed assembly with protection class IP42 and DC brushless motor guarantees long service


	MS-H-S stainless steel with ceramic coated hotplate

Specifications

	MS-H-S
Dimension of work plate [mm]	φ135（5 inch）
Work plate material	Stainless steel with ceramic coated
Motor type	DC brushless motor
Motor rating input [W]	18
Motor rating output [W]	10
Power [W]	530
Voltage [VAC]	200-240
Frequency [Hz]	50/60
Stirring positions	1
Max. stirring quantity[H₂O], L	20
Max. magnetic bar(L x Ø) [mm]	80
Speed range [rpm]	0-1500
Speed display	Scale
Heating output [W]	500
Heating temperature range [°C]	RT-340
Safety temperature [°C]	350
Temperature display	Scale
External temperature sensor	N/A
Heating warning [℃]	N/A
Remote control (RS232 interface)	N/A
Protection class according to DIN EN60529	IP42
Dimension [W x D x H] mm	160×280×85
Weight [kg]	2.8
Permissible ambient temperature [℃]	5-40
Permissible relative humidity	80%

Information

Cat No.	P/N	Descriptions	Power supply
811421020000	MS-H-S	BlueSpin Classic Hotplate Magnetic Stirrer，stainless steel with ceramic coated hotplate，heating temperature up to 340°C	USA plug,100V-120V/50Hz/60Hz
811421010000			Cn plug,200V-240V/50Hz/60Hz
811421050000			Euro plug,200V-240V/50Hz/60Hz
811421060000			UK plug,200V-240V/50Hz/60Hz
Accessories
18900006	MSBAR10	Stirrer bar (10mm x 6mm)，1pc/pk
18900007	MSBAR15	Stirrer bar (15mm x 8mm)，1pc/pk
18900008	MSBAR20	Stirrer bar (20mm x 8mm)，1pc/pk
18900009	MSBAR25	Stirrer bar (25mm x 8mm)，1pc/pk
12500005	MSBAR30	Stirrer bar (30mm x 6mm)，1pc/pk
18900011	MSBAR40	Stirrer bar (40mm x 8mm)，1pc/pk
12500004	MSBAR50	Stirrer bar (50mm x 8mm)，1pc/pk
18900013	MSBAR65	Stirrer bar (65mm x 8mm)，1pc/pk
18900014	MSBAR80	Stirrer bar (80mm x 13mm)，1pc/pk
18900015	MARRM	Stirrer bar remover, length of 200mm, 1pc/pk
18900019	F101	F101 protective cover, for hotplate model, use with MS-H-Pro + and MS-H-S

Accessories

		Stirrer bars and stirrer bar remover（PTFE）, use below 150℃
		Models
		MS-H-Pro+	MS-H280-Pro	MS-H-S10
		MS-H-S	MS-PA	MS-M-S10
		MS-S	MS-PB
Cat. No.	Size of stirrer bars [mm]	Suitable for Max. stirrer bar 80mm	Suitable for Max. stirrer bar 50mm	Suitable for Max. stirrer bar 40mm
18900006	10mm x 6mm	●	●	●
18900007	15mm x 8mm	●	●	●
18900008	20mm x 8mm	●	●	●
18900009	25mm x 8mm	●	●	●
12500005	30mm x 6m	●	●	●
18900011	40mm x 8mm	●	●	●
12500004	51mm x 8mm	●	●
18900013	65mm x 8mm	●
18900014	80mm x 13mm	●
18900015	Stirrer bar remover, length of 200mm	●	●	●
