MS-H-S10 10-Channel Classic Magnetic Hotplate Stirrer

Detailed description

MS-H-S10
10-Channel Classic Magnetic Hotplate Stirrer

Features of MS-H-S10

- Heating temperature up to 120°C

- High performance multi-position magnetic stirrer with uniform temperature distribution
- Individually controlled stirring for consistency with various samples
- Individually controlled stirring for consistency with various samples
- Electronic speed control motor provides constant speed
- DC brushless motor maintenance free and quiet running
- Stainless steel plate with silicone films, anti-slip and anti-corrosion

MS-H-S10
stainless steel with silicone Film

Specifications

	MS-H-S10
Dimension of work plate [mm]	180×450
Work plate material	Stainless steel with silicone Film
Motor type	DC motor
Motor rating input [W]	12
Motor rating output [W]	4
Power [W]	490
Voltage [VAC]	200-240
Frequency [Hz]	50/60
Stirring positions	10
Max. stirring quantity[H₂O], L	0.4 (each stirring position)
Max. magnetic bar(L x Ø) [mm]	40
Speed range [rpm]	0-1100
Speed display	Scale
Heating output [W]	470
Heating temperature range [°C]	RT-120
Safety temperature [°C]	140
Temperature display	Scale
Protection class according to DIN EN60529	IP42
Dimension [W x D x H] mm	182×552×65
Weight [kg]	3.2
Permissible ambient temperature [℃]	5-40
Permissible relative humidity	80%

Information

Cat No.	P/N	Descriptions	Power supply
811321020000	MS-H-S10	10-Channel Classic Hotplate Magnetic Stirrer, stainless steel plate with silicone film, heating temperature up to 120°C	USA plug,100V-120V/50Hz/60Hz
811321010000			Cn plug,200V-240V/50Hz/60Hz
811321030000			Euro plug,200V-240V/50Hz/60Hz
811321040000			UK plug,200V-240V/50Hz/60Hz
Accessories
18900006	MSBAR10	Stirrer bar（10mm x 6mm），1pc/pk
18900007	MSBAR15	Stirrer bar（15mm x 8mm），1pc/pk
18900008	MSBAR20	Stirrer bar（20mm x 8mm），1pc/pk
18900009	MSBAR25	Stirrer bar（25mm x 8mm），1pc/pk
12500005	MSBAR30	Stirrer bar（30mm x 6mm），1pc/pk
18900011	MSBAR40	Stirrer bar（40mm x 8mm），1pc/pk
18900015	MARRM	Stirrer bar remover, length of 200mm, 1pc/pk

Accessories

		Stirrer bars and stirrer bar remover（PTFE）, use below 150℃
		Models
		MS-H-Pro+	MS-H280-Pro	MS-H-S10
		MS-H-S	MS-PA	MS-M-S10
		MS-S	MS-PB
Cat. No.	Size of stirrer bars [mm]	Suitable for Max. stirrer bar 80mm	Suitable for Max. stirrer bar 50mm	Suitable for Max. stirrer bar 40mm
18900006	10mm x 6mm	●	●	●
18900007	15mm x 8mm	●	●	●
18900008	20mm x 8mm	●	●	●
18900009	25mm x 8mm	●	●	●
12500005	30mm x 6m	●	●	●
18900011	40mm x 8mm	●	●	●
12500004	51mm x 8mm	●	●
18900013	65mm x 8mm	●
18900014	80mm x 13mm	●
18900015	Stirrer bar remover, length of 200mm	●	●	●
